    Cold Welding Machine / Wire Making Machine 4mm To 8mm Cu And 4mm To 15mm

    Ask Lasest Price
    Brand Name : Newlead
    Model Number : 4/8
    Price : Negotiation
    Certification : ISO CE
    Supply Ability : 1 set in 60 days
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    Cold Welding Machine / Wire Making Machine 4mm To 8mm Cu And 4mm To 15mm

    Cold welding machine for copper rod breakdown machine 4mm to 8mm Cu and 4mm to 15mm Al​



    copper rod breakdown machine with annealer


    1.wire drawing and annealing in a single, compact

    unit

    2.2-zone annealing system, electrically neutral

    (no current flow to other machines)

    3.ergonomic and user-friendly machine design,

    with easy maintenance

    4.left and right-hand versions for Non Ferrous

    metal wires with the highest quality

    requirements

    5.digital annealing voltage control for consistent

    wire annealing quality

    6.closed wire path for reduced consumption of

    protective gas

    7.freely accessible slip rings and carbon brushes

    coolant system integrated in the annealer (incl.

    tank, heat exchanger and pump)

    8.single wire path with no crossover

    9.effective single-wire drying

    machine type

    8DT

    9DT

    11DT

    13DT

    inlet diameter (mm)

    φ8

    φ8

    φ8

    φ8

    outlet diameter (mm)

    φ2.6-φ4.0

    φ2.2-φ4.0

    1.60-4.0

    φ1.2-φ4.5

    transmission type

    transmit by high precision

    drawing line speed(MPM)

    780

    780

    1500

    1500

    lubrication system of wire drawing

    all immerse type

    capstan dia.(max.) (mm)

    φ450

    φ450

    φ450

    φ450

    fix speed capstan dia.(mm)

    φ450

    φ450

    φ450

    φ450

    main motor (KW)

    160(DC)

    160(DC)

    250(DC)

    280 (DC)

    drawing dies no./max

    8

    9

    11

    13

    annealing medthod

    DC three section spooler

    max.anneaing voltage (DC)

    55V

    55V

    55V

    60V

    max.anneaing current (DC)

    4000A

    4000A

    4000A

    5000A

    Drive method

    D.C. drive
