| Brand Name : | NEWLEAD |
| Model Number : | 4500 |
| Price : | Negotiation |
| Certification : | ISO CE |
| Supply Ability : | 1 set in 60 days |
| Delivery Time : | 60 days |
4500 Wire Enameling machine for 0.25-0.6mm New Technology only hlaf consumption
Advanced technoloy:
1: No waste gas ,three time fully burning,no smell.
2:only 300kw.h in 24 hours,heat energy recycling to annealer and dryer.
One. Equipment technical parameters and features
1. Wire range: Φ0.3mm -Φ0.6mm
2. Lines: 24
3. Painting pass: 8
4. Painting style :Dies
5. Distance of lines: 7mm
6. Maximum speed: 150m/min
7. Take-up spool specifications: PT15-PT25
8. pay-off spool specifications :Φ400 mm
9.The total installed capacity : about 120kw
| specificationsΦ:(MM) | Lines | Painting channels | DV value | speed(M/Min) | Output Kg/24h | energy consumption Kw.h/24h | ||||
| QZ-2 | QA-2 | QZ-2 | QA-2 | QZ-2 | QA-2 | QZ-2 | QA-2 | |||
| O.25 | 24 | 8 | 25 | 100 | 1500 | 500kw.h/24 | ||||
| 0.30 | 24 | 8 | 25 | 83 | 1793 | |||||
| 0.40 | 24 | 8 | 25 | 62 | 2381 | |||||
| 0.50 | 24 | 8 | 25 | 50 | 3000 | |||||
| 0.60 | 24 | 8 | 25 | 42 | 3629 | |||||

|
