    26D Copper Wire Drawing Machine , Inlet Material 1.6mm Max Welding Electrode Making Machine

    Ask Lasest Price
    Brand Name : RBO
    Certification : CE
    Price : Negotiation | 1 Unit/Units wire stripping machine (Min. Order)
    Model Number : 26D
    Supply Ability : 20 sets in 60 days
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    26D Copper Wire Drawing Machine , Inlet Material 1.6mm Max Welding Electrode Making Machine

    26D Big poduct range fine wire drawing machine Inlet material 1.6mm max


    Product Description


    1: wire drawing in a single, compact

    unit

    2: ergonomic and user-friendly machine design,

    with easy maintenance

    3: left and right-hand versions for Non Ferrous

    4: metal wires with the highest quality

    5: Big rang inlet Max 1.6mm

    6: Big drawing motor 18.5KW


    machine type26D24DS
    inlet diameter(mm)1.0--1.6
    outlet diameter(mm)0.1--0.4
    drawing line speed(MPM)2400
    drawing dies No./Max26
    slip ratio of m/c13%
    fix speed capstan slip ratio8%
    capstanceramic plasma
    capstan dia.(max.)(mm)φ242
    fix speed capstan dia.(mm)φ207
    frameirone cast
    main motor18.5KW three phase inductor motor
    spooler motor4KW three phase inductor motor
    revise systemDual inverter control
    inverter controlDual inverter control
    transmission typeflat belt
    payoff methodover head
    traversing unitflat belt + timing motor
    tension controlweightbalance by swing arm
    lubrication system of wire drawingspray
    suitable diameter of spool (mm)φ300
    capacity for wire receiving(kg)50-60
    bobbin loading & unloading typeshaft type
    power source380V/220/415/480 OEM
    brakepneumatic brake
    machine dimension2150L×1600W×1900H
    machine weight2000

    Product Picture
