    Cold Welding Intermediate Wire Drawing Machine 1.0mm To 3.25mm Desktop Type

    Ask Lasest Price
    Brand Name : Newlead
    Certification : CE
    Price : Negotiation
    Model Number : 1.0mm to 3.25mm
    Supply Ability : 5 sets in 15 days
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    Cold Welding Intermediate Wire Drawing Machine 1.0mm To 3.25mm Desktop Type

    The range of wire 1.0mm to 3.25mm cold welding machine for Intermediate wire drawing machine Desktop type



    Advantages of this safe investment choice

    Design

    © optimized wire cooling/lubrication (fully-immersed drawing basin)

    © helically geared precision gearing for extremely smooth operation and uniform load transmission

    © vibration-damping black cast iron housing for long service life

    © highly reliable separation of drawing emulsion and gear oil via mechanical seal(long service intervals)

    © user-friendly design

    Improve in quality:

    © high surface quality of the wires due to the optimized wire path(2°C inclination of the gearing/drawing capstans)

    Improve in productivity:

    © reduced downtime when changing the machine setup for different dimensions via multi-motor drive technology(quick drawing die change system)

    © reduced downtime due to touchscreen based user guidance and fault display


    machine

    11DST

    inlet diameter(mm)

    Φ3.5-3.0

    outlet diameter(mm)

    Φ0.8-φ2.76

    drawing line speed(MPM)

    900

    drawing dies No./Max.

    11

    slip ratio of m/c

    19.5%

    fix speed capstan slip ratio

    16.5%

    capstan

    tungsten

    capstan dia.(max.)(mm)

    Φ280

    fix speed capstan dia.(mm)

    φ 260

    frame

    weld,two conjunctions

    main motor

    55KW,ACmotor

    spooler motor

    15KW AC motor

    revise system

    PID synchronous spooler

    power control

    AC motor inverter control

    transmission type

    gear

    Payoff method

    over head

    traversing unit

    decelerate motor

    tension control

    pneumatic balance by swing arm

    lubrication system of wire drawing

    all immerse type

    suitable diameter of apool (mm)

    PND630

    capacity for wire receiving (kg)

    200-500

    power source

    380V

    brake

    pneumatic
